DB-MJPT

Description

The D-MJPT is a Decora style wall plate with a mini-jack (3.5 mm, 1/8″) input or output connector. The front-panel jack is directly connected to a second mini-jack on the rear of the D-MJPT. The panel is ideal for mounting in a wall or in an RDL DC-1 Decora style countertop chassis. The mini-jack pass-through allows quick installation to provide user audio connections between the jack plate and a computer or other audio product that connects through a mini-jack. The standard model (D-MJPT) is finished in RDL standard white/gray. The DS-MJPT is constructed in stainless steel with custom labeling available through RDL.
