TX-AFC1F

Balanced to Unbalanced Audio Transformer – XLR, RCA

• Studio Quality Bifilar Audio Transformer
• Galvanic Isolation with the Convenience of RDL® TXs™
• Connectorized with Gold Contacts on Input and Output
• Balanced to Unbalanced Conversion
• Professional to Consumer Level Conversion
• Frequency Response: 20 Hz to 20 kHz (+/- 0.1 dB)
• THD: < 0.06% (50 Hz to 20 kHz, +4 dBu input)
  0.0015% (Typ. 1 kHz, +4 dBu input)
• Input: +4 dBu (+22 dBu max.), 2.5 kΩ Bridging, XLR
• Output Level: -10 dBV, Phono jack
• CMRR: >85 dB (balanced input, 50 to 60 Hz)
