UV100 series is a dedicated intelligent auto-tracking camera, with cutting-edge technology in the field of education informatization. It includes a lecturer camera UV100T and a student camera UV100S. UV100 series is built-in with a high-speed processor, advanced image processing and analysis algorithms to track lecturers and students accurately and quickly, which is in line with the requirements of lecturer capture and remote interactive teaching.
UV100 series adopts advanced ISP technologies and algorithms, to make a vivid image quality, screen brightness uniformity, strong sense of depth, high-definition, and fantastic color rendition. As a stable, reliable and simple machine to operate, the UV100 series has full function and high performance. Easy to install and maintain.
Integrated design: built-in panoramic camera, to achieve an integrated fusion of panoramic camera and tracking camera.
Advanced tracking algorithms: the use of advanced human detection, locking and tracking image processing, analysis algorithm to ensure the target tracking steady, accurate and fast.
Strong anti-interference ability: Once the tracking target is locked, not affected by the disturbances of other moving objects and projectors et
Smooth tracking: The sensitivity of action can be adjusted. Tracking the target’s small movement or gestures will not cause the camera’s misoperation.
Video image auto adaptation: Based on the distance of tracking a target, the tracking camera will automatically zoom and the video image will always maintain the appropriate size and proportion.
Strong environmental adaptability: The tracking performance is not affected by the classroom’s size, shape and seating arrangement.
Ultra-wide dynamic exposure function: to completely avoid the problem of tracking target darken under the strong light background of projectors etc.
Superb High-definition Image UV100 employs 1/2.8 inch high-quality CMOS sensor. Resolution is up to 1920×1080 with a frame rate up to 60 fps.
Low Noise and High SNR Low Noise CMOS effectively ensure high SNR of camera video. Advanced 2D/3D noise reduction technology is used to further reduce the noise while ensuring image sharpness.
Wide-range, Quiet and Quick Pan/Tilt Mechanism By adopting the step driving motor mechanism, UV100 camera works extremely quiet and moves smoothly without any noises.
Multiple Network Protocol Support ONVIF, RTSP, RTMP protocols and support RTMP push mode.
Low-power Sleep Function Support low-power sleep/wake up, the consumption is lower than 400mW under sleep mode.
Audio Input Interface Support 16000,32000,44100,48000 sampling frequency and AAC,MP3,PCM audio coding.
Multiple Video Compression Support H.264/H.264+ video compression. Support compression of resolution up to 1920×1080 with frame up to 60 fps and 2 channels 1920x1080p with 30 fps compression.
