Minrray UHD PTZ camera, USB3, HDMI, LAN. Brushless Motor Video Conferencing Cam

UV401A

$4,770.00

* Check with us for the latest pricing

4k Video Conference Camera

Ultra HD, Wide viewing angle, Electronic pan/tilt, Multi-protocols
Data Sheet | Related Products | Minrray Products

UV401 Ultra HD 4K camera has perfect functions and superior performance, which adopts advanced ISP processing algorithms to provide vivid images with evenly clear brightness, intense color layering, high the resolution, and fantastic color rendition.

Key Features

Brushless Motor
Built-in brushless DC motor with Variable Speed Technology, which make pan/tilt features extremely quiet PTZ, super speed, high accurate presets, closed-loop control etc.

4K Ultra HD Image
UV401 adopts 1/2.5, 1/1.7 inch, 12.40-megapixel high-quality SONY CMOS sensor. Resolution is up to 4K with a frame rate up to 60fps.

Multiple Optical Zoom Lens
12X optical zoom lens offer 82.6°/ 80.4° wide angle without distortion.

Leading Auto Focus Technology
Leading auto focus algorithm makes lens autofocus more quickly, accurately and stably.

Low Noise and High SNR
Low Noise CMOS effectively ensure high SNR of camera video. The adoption of advanced 2D/3D noise reduction technology not only further reduces the noise, but also ensuring image sharpness.

Multiple Video Output Interfaces
Support HDMI, USB3.0, LAN. HDMI, LAN support audio output.

Multiple Audio/Video Compression Standard
Support H.264/H.265 video compression, AAC, MP3 and G.711A audio compression and 3840×2160 resolution with a frame rate up to 60fps compression.

Audio Input Interface
Support 8000, 16000, 32000, 44100, 48000 sampling frequency and AAC, MP3, G.711A audio coding.

Built-in gravity sensor
Built-in gravity sensor, support the automatic flip function of the gimbal, convenient for engineering installation.

Multiple Network Protocols
Support ONVIF, GB/T28181,RTSP, RTMP protocols, RTMP push mode, which is easy to link streaming media serve (Wowza, FMS), RTP multicast mode and network full command VISCA control protocol.

Control interface
RS422(compatible with RS485), RS232; RS232 support cascade, easy to install and use.

Multiple Control Protocol
Support VISCA, PELCO-D, PELCO-P protocols and Automatic identification protocol.

Multiple Preset
Support 255 preset positions (the remote controller is set to 10 preset positions).

Multiple Remote Controller
Users can choose an infrared remote controller or wireless remote controller according to the environmental conditions.2.4G wireless remote controller is not affected by the angle, distance, infrared interference. Support remoter signal pass-through function, which is convenient for back-end use.

Wide Application
Tele-education, Lecture Capture, Webcasting, Videoconferencing, Tele-training, Tele-medicine, Interrogation and Emergency command systems.
UV401A


Data Sheet | Related Products | Minrray Products
