Terracom Terra-AMP: Amplified IP Terminal

TERRA-AMP

P.O.A

* Ex GST. Check with us for Discounts and the latest Trade pricing!


Terra-AMP: Amplified IP Terminal

TERRA-AMP is an IP audio terminal with built-in 2 x 15 W amplifier on two independent outputs, USB flash memory interface for playlist backups or prerecorded announcement, 1mic/line balanced input.

In a lot of applications this amplified IP terminal for 8-ohm speakers reduces price and space. The ideal solution for Commercial Audio & Public Address systems. The mic & line inputs can be played locally or can be used as a source for a network stream.

Features:
  • 1 mic/line balanced input
  • 2 balanced independent line outputs
  • 2 x 15 W (8 ohm) independent amplified outputs
  • 1 headphone output on mini-jack.
  • Audio inputs: maximum level + 5 dB, bandwidth 20 Hz - 20 kHz
  • Audio outputs: maximum level + 5 dB, bandwidth 20 Hz - 20 kHz
  • Ethernet interface including POE (Power over Ethernet).
  • 24 VDC power supply (if no POE available).
  • G.711, G.722, MP3 audio encoding/decoding.
  • 1 USB port for USB memory stick
  • Power & Status LED.
  • 3 contact inputs
  • 2 relay outputs
  • RS 232 on Euro Block
  • Power consumption: 5.7 W with POE / 13.44 W (With 24 VDC IN)
  • Weight: 460 g
  • Dimensions (mm): Depth 104, Height 32, and Width 109.

Refer to the wider TERRA range for audio encoders, audio decoders, audio over IP and IP audio systems

View the Terra-AMP Datasheet here.
